Raspberry Pi Camera HD v3 Wide 12MPx - original camera for Raspberry Pi

A wide-angle version of the third installment of the official Raspberry Pi camera . The module can be connected directly to the Raspberry Pi minicomputer connector. The camera is equipped with a Sony IMX708 sensor with a resolution of 12 Mpx, supports a wide dynamic range (HDR - High Dynamic Range) and autofocus, the sensitivity in low light has been improved. The camera's angle of view (FoV) is 120° . The Raspberry Pi minicomputer has hardware support for this camera, so it does not consume the processor's computing power. The Raspberry Pi OS system has the appropriate drivers for the camera, so there is no need to install them yourself, and the configuration of the camera itself is simple and user-friendly. In our offer you will also find a camera with a smaller angle of view of 76°, a night camera without an IR filter and a night camera with a larger angle of view .

Main Features of Raspberry Pi Camera v3

• 12-megapixel Sony IMX708 CMOS sensor



• High signal-to-noise ratio (SNR)



• Built-in 2D Dynamic Pixel Defect Correction (DPC)



• Phase Detection Autofocus (PDAF) for fast autofocus



• QBC re-teasing function



• HDR mode (output up to 3 megapixels)



• CSI-2 serial data output



• 2-line serial communication (supports I2C fast mode and fast mode plus)



• 2-line serial control of the focus mechanism

Raspberry Pi Camera HD v3 specification

• Sensor: Sony IMX708



• Matrix resolution: 11.9 MPx



• Focal length: 2.75mm



• Sensor size: 7.4 mm diagonal



• Pixel size: 1.4 x 1.4 μm



• Resolution: 4608 x 2592 px



• Video modes: 1080p50, 720p100, 480p120



• Output: RAW10



• Viewing angle: 120°



• Aperture: F2.2



• Focus setting: autofocus



• Focus range: 5 cm to infinity



• HDR: yes



• IR filter: no



• Belt length: 200 mm



• Connector: 15x1mm FPC



• Dimensions: 25 x 24 x 12.4mm
